Moda Spring Hinge - Satin Chrome Plate
Specification
| Material | Diecast Zinc, Alloy ZP3 Brass Shaft Nylon Inserts ABS Snap-On Covers |
| Finish |
Satin Chrome Plate |
| Mounting | Concealed Screw Fix or Bolt Through |
| Minimum Hinge Clearance For Lift-Off Hinges | Ā 35mm |
|
Specify
|
MODA_LHSPRING_SCP:Ā Left Hand
MODA_RHSPRING_SCP:Ā Right Hand
|
| Features | Spring-assisted door opening/door closing Fully Adjustable Spring to suit door - No Tension to Full Tension Spring Reversible Hold Open / Hold Closed Liftoff capability |
| Load Rating | 15Kg per hinge |
| Ā |
For optimum performance - Note:Ā 3 Hinges per door is recommended to prevent door bowing |
| Note |
For Bolt Through useĀ 106C_FACEPLATEĀ Concealed Fix Face Plate (Available in Satin Chrome Plate only) All hinges are available with or without fixings.Ā Please nominate your requirements at the time of ordering. |
